Good Quality Flexible Soft Plastic Hose PVC Clear Hose for Liquid water

Short Description:

This kind of pvc clear hose is used for conveying water, oil, gas under normal working pressure in the factory, farm, building and family, fishery, aquarium.

Send email to us

Product Detail

Product Tags

Technical Parameters

Working temperature : -5℃ ~ +65℃

* Colors, thickness, hardness, widths and length of this PVC hose can be customized.

* This product could be made into food grade.

Our product is made of superior PVC raw materials to ensure our hose is durable, anti-heat, anti-cold and no smell. We use special PVC formulations to make sure our products could be transparent enough or brightly color.

This food grade pvc transparent hose could be used to transfer water, milk, oil even corrosive liquid in low pressure. This kind of hose inner surface is very smooth, not easy to scale and users could check the transportation of liquid clearly.

Its working temperature could be -5℃~ 65℃

Clear PVC Hose

Clear PVC Hose, transparent hose pipe always conveying many liquids and gases. Also used as suds pipes and protection of metal tubes, wooden dowelling, and yacht rigging. Clear PVC hose makes it easier to view the liquid inside the tubes, which can prevent kinks and the incorrect transfer of liquids through certain lines. Suitable for food, medical and contact applications.Clear PVC hose piping provides a versatile, cost-effective alternative for many piping applications, particularly those where visual monitoring is critical.

Alias: Flexible Clear PVC Hoses, Flexible Transparent PVC Tubing, Clear PVC plastic tubing, Clear VinyI PVC tubing, Transparent pipeline.

Product Display

Product Parameters

Type	Fiber Hose
Brand	MIQER
Place Of Origin	Shandong, China
Place Of Origin	China
Size	8mm-160mm
Color	Red/Yellow/Green/White/As Customers Requirements
Product Features	Being Colorful, Flexible, Elastic, Durable, Nontoxic, Adaptable To High Temperature Under High Pressure Conditions And Long Lasting .
Craft	Hot Melt Method
Shape	Tubular
Material	Pvc
Material	Pvc
Size	Customized
Surface Treatment	Smooth
Technics	Hot Melt Method
Application	Washing The Car, Watering The Ground
Sample	Free
Certification
Oem	Accept
Capacity	50mt Per Day
Color	Red/Yellow/Green/White/As Customers Requirements
Minimum Order Quantity	150meter
Fob Price	0.5~2susd/Meter
Port	Qingdao Port Shandong
Payment Term	t/t,l/c
Supply Capacity	50mt/Day
Delivery Term	15-20 Days
Standard Packaging	Wound In Roll, And Packing Use Carton

Specifications of PVC Transparent Hose
Hose Metric				Hose Metric
Measurement		Weight	Length	Measurement		Weight	Length
I.D.	O.D.			I.D.	O.D.
mm		g/m	M	Mm		g/m	M
3	5	17	588/10kg	14	17	98	101/10kg
4	6	21	472/10kg	14	18	135	148/20kg
4	7	35	286/10kg	14	19	174	114/20kg
5	7	25	394/10kg	16	19	111	180/20kg
5	8	41	242/10kg	16	20	152	131/20kg
6	8	29	338/10kg	16	21	196	102/20kg
6	9	48	210/10kg	18	22	169	117/20kg
8	10	37	270/10kg	18	24	267	75/20kg
8	11	60	166/10kg	19	24	227	88/20kg
8	12	85	118/10kg	20	24	186	107/20kg
10	12	46	215/10kg	25	27	110	181/20kg
10	13	73	137/10kg	25	29	228	88/20kg
10	14	100	100/10kg	25	31	356	56/20kg
12	15	85	233/20kg	32	38	445	45/20kg
12	17	153	130/20kg	32	39	526	38/20kg

Product Details

Specification of Clear PVC Hose

Clear Vinyl Tubing manufactured with non-toxic material. Can be used for flexible lines for low-pressure air, water, liquids,beverages, chemicals, and gases as well as drain lines for air conditioners and dehumidifers. Excellent resistance to mild acids and chemicals. See-through design allows for visual flow. Not for use with ice makers or petroleum-based products.

Differnt Range Of Sizes & Color PVC Hose

The I.D.(Inner diameter) of this clear hose could be 3mm ~ 25mm. And all of the transparency, hardness and color of this hose could be customized. So this product is suitable for use in industry and agriculture, project, fishery breeding, also can be used as a door lock handle sheath, craft gift packaging and children's toys.
